SIMLOG Reach Lift Truck Simulator

Simlog Announces new Industrial Controls for Reach Lift Truck Personal Simulator

Reach Lift Truck Personal Simulator Setup with Three Displays



Compared with the Reach Lift Truck Tabletop controls using replica controls + Logitech G920 in either a Crown or Raymond style configuration, the new Console feature true Industrial and Original Equipment Components.

In this first configuration for Crown, the Industrial Controls can be positioned for training in

  • Programs with real Crown reach lift trucks for training
  • Workforce training for employers with Crown fleets or predominantly Crown
  • Customer simply want the realism of an Industrial OEM simulator regardless of manufacturer, Crown or Raymond



Simlog Inc., the pioneer and standard in affordable PC-based heavy equipment simulators for operator training in education and industry, is pleased to announce the availability of new USB-ready Industrial Controls for Reach Lift Truck Personal Simulator.

Developed in response to demand from customers for a superior simulation experience, they feature the following key elements:

  • OEM Multi-Task Handle, to travel forwards/backward, raise/lower the forks, extend/retract the forks, shift left/right, etc.
  • Steering Tiller, that faithfully reproduces the look and feel of real reach lift truck operator controls
  • Foot Brake Pedal Unit
  • Two Pushbuttons, to present alternative viewpoints (especially important when there is just one display)
  • Mini-joystick, to pan/tilt the current viewpoint
  • Emergency Power Disconnect Pushbutton
  • Front Panel Key Lock, to restrict access to the desktop PC placed inside

The Industrial Controls are mounted on an Industrial Console for stand-up use, with casters for easy portability.

Pricing & Availability

Simlog’s new Industrial Controls for Reach Lift Truck Personal Simulator is now available for ordering. They arrive fully assembled, and USB-ready to connect to your PC and displays.

Alternatively, Simlog can provide an embedded computer as part of a “PC Bundle”, if a “turnkey” system is preferred.

Please contact Klein Educational Systems for pricing.


Simlog’s new Reach Lift Truck Personal Simulator puts you at the controls of a typical stand-up “narrow aisle” lift truck with a scissors-like pantograph to extend and retract the forks (also called “Reach Truck”) suitable for OSHA Class 2 operator training programs.

 We also have a (sit-down counterbalance) Forklift Personal Simulator so you can train people to operate both kinds of lift trucks with our help.

 Training scenarios are typical of warehouses and distribution centers where racking systems are tall and spaced closely together to increase storage density.

 There are many software options to configure what you see and do, to reproduce the operator controls and steering behavior of the most common kinds of (real) reach lift trucks.

 Set up just one display where space is limited, or three displays placed to the left, in front, and to the right, to present views that are typical of “side stance” positioning when looking backward, in front, and forwards.

 And all you need is one off-the-shelf computer. Either purchase your own off-the-shelf  PC or choose the convenience of our PC bundle with Simlog software already installed, licensed, and ready to go in English, French, or Spanish.

Reach Lift Truck Personal Simulator Replica Controls

 Replica Controls for the Reach Lift Truck Personal Simulator feature industrial-strength USB-ready input devices and special tabletop mounting brackets to work from a standing position, just like in the cabin of real reach lift trucks.

 For the left hand, there is a horizontally-positioned steering wheel, the Logitech “G920 Driving Force Racing Wheel”, that can also be used with many other Personal Simulators. There is also a steering wheel “knob” for turning the  steering wheel with just one hand.

 (Real reach lift trucks also have pedals, but that’s functionality primarily intended for safety, not operations. For that reason, and to keep costs down, our simulator controls at this time include no such pedals.)

 In most countries, the Logitech G920 is for sale in retail stores that sell computers or video games, but it may also be purchased on-line. (Logitech’s previous model, the “G27 Racing Wheel” can also be used.)

 For the right hand, there is a “control lever” (a two-axis joystick) to control travel forwards and backward. The control is proportional: push a little to move slowly; push more to move quickly.

 Practically, real control levers are positioned either vertically or horizontally (the most common arrangement) so at Simlog, you can do both.

 For vertical positioning, there’s a multi-purpose Replica Control joystick that can also be used with many other Personal Simulators. Moving the joystick forwards/backward controls travel forwards/backward; moving the joystick left/right controls the up/down motion of the forks. Alternatively, with vertical positioning, control of the forks can also be associated with pushbuttons on the joystick.

For horizontal positioning, Simlog offers a different joystick model with a stiffer spring and an oval-shaped face, as shown here. Moving the joystick forwards/backward controls the travel forwards/backward; moving the joystick up/down controls the up/down motion of the forks. (You can also re-position this joystick vertically, to train operators in both ways.)

In both cases, pushbuttons on the joystick are used to extend/retract the pantograph, to side shift, to tilt the forks, and to change the viewpoint during simulation e.g. by “leaning” left/right.

arrow_bulet Possible Setups
There are two possible setups as follows:

  • one display in front, to present the view looking forwards
  • three displays placed to the left, in front, and to the right to present views that are typical of “side stance” positioning when looking backwards, in front, and forward

Here we present both setups, for the case where the joystick is positioned horizontally.

Custom Travel Cases for Replica Controls

As for other Personal Simulators, Simlog’s Custom Travel Case makes transportation easy.

arrow_bulet Key Features

  • Made-to-measure, with dedicated slots for the steering wheel, joystick, and tabletop mounting bracket
  • Space for a laptop PC, cables, and documentation
  • Pull-out handle, with multiple positions
  • Wheels (casters)
  • Cases are “stackable,” for easy transport.

arrow_bulet Specifications

  • Overall dimensions: 30″ (76cm) x 24″ (61cm) x 19″ (50cm)
  • Approximate weight: 50 lbs. (23 kg) when empty, up to 100 lbs. (46 kg) when full (depending upon the Replica Controls.)



Click here for a video of the new SIMLOG REACH TRUCK SIMULATOR







Klein eLearning Web Meetings

Klein Educational Systems

With the immediate need for a relevant curriculum and a delivery system that is quick to implement and easy to use, Klein Educational Systems is working together with Amatrol to provide web-based technical training.

Amatrol eLearning

Twice a week on Tuesday and Thursday at 10 am and 2 pm Dan Whalen and Chris Gura will be hosting interactive zoom web meetings to present training, familiarization and general help for those that are either using the Amatrol eLearning Program or who may be interested in using the Amatrol eLearning Program.

Please contact either

Dan Whalen - dThis email address is being protected from spambots. You need JavaScript enabled to view it.

or

Chris Gura - This email address is being protected from spambots. You need JavaScript enabled to view it.

To get scheduled for one of these meetings.



Klein's technicians and sales reps are always ready to help you get set up with a Demo of the Amatrol eLearning.

Here is a link to the available courses (https://www.learnamatrol.com/courses.php)

This Demo will be the full curriculum for the course you choose and be good for 21 days.

If you are ready to dive into Amatrol eLearning you can contact us at This email address is being protected from spambots. You need JavaScript enabled to view it. or 1-800-698-3249



Amatrol’s Virtual Simulators

Interactive Technical Skill Development, Hands-On Virtual Simulators!

Amatrol is bringing industrial realism to online learning through our new Virtual Simulators. Students can now get the look and feel of using real equipment via their computer. The Virtual Simulators replicate hands-on equipment in such great detail that students will feel like they are using the actual equipment. Students perform essentially the same industry-based tasks using the virtual equipment that they would perform using equipment hardware. With strong market pressure to gain skills quickly, virtual simulators let students develop skills at the speed of business.

  • Real world outcome based on student input
  • Immediate feedback given for self-teaching
  • Convert from trainer to industrial components to ensure real world experience
  • Authentic adjustments
  • Component hook-up to give look and feel of real lab equipment

A key challenge of every learning environment is to match learning material to different learning styles. In Amatrol’s interactive multimedia, visual, auditory, and text based learning styles reinforce each other in well organized learning segments. Repetition, active problem solving, and self-reviews all provide feedback to students to build confidence in the skills they develop.Each topical area starts with basic concepts and then leads the student into a layered learning process of increasing depth. Practical application of the knowledge is central to all Amatrol learning materials. Students develop knowledge and then learn how to apply that knowledge to modern industry.

As an example, here are some of our more popular eLearning courses with Virtual Trainers:

Available Training Systems

Virtual Trainers come standard with more than 20 Amatrol training systems spanning six different technologies:





COVID-19 Update

Klein Educational Systems


4-2-2020

First and foremost, our thoughts go out to the families, communities, and schools that have been negatively impacted by the pandemic. We hope everyone stays healthy and can go back to normal life sooner rather than later.

We are here to help.

Amid this uncertainty, we wanted to assure you that we are fully operational and here to support your school through the changes needed to reach your students remotely. We have partnered with educators for over 40 years to provide high-quality teaching resources, and we are here to help you. We have made the necessary adjustments in our workflow to ensure the safety of our employees, while still allowing us to provide exceptional service to our customers.

We offer numerous eLearning platforms to help adapt to online education. Please reach out to us to schedule a webinar to discuss the best options available to finish the school year.
email us at This email address is being protected from spambots. You need JavaScript enabled to view it. or call us at 1-800-698-3249.

The U.S. Department of Labor Has Officially Approved the MSSC CPT as a High-Quality, Nationwide High School Pre-apprenticeship Earn-and-Learn Program!

In January 2018, the U.S. Department of Labor (DOL) officially approved TWO different MSSC CPT High School Pre-apprenticeship programs as meeting DOL criteria for a high-quality, nationwide high school pre-apprenticeship earn-and-learn competency-based programs.

Program 1: 720-hour MSSC High School Pre-Apprenticeship

-Related Training: 80 hours junior year and 80 hours senior year. During this portion of this program, the candidate earns the industry-recognized, nationally portable MSSC Certified Production Technician (CPT) or the hands-on CPT+.

-On the Job Learning (OJL): 280 hours (8 weeks) in the summer of junior year and 280 hours (8 weeks) in the summer of senior year, for which the student will receive a stipend from the participating employer program.

Program 2: 3,000 hour Industrial Manufacturing Technician Apprenticeship (IMT)

-Apprentices will learn to set up, operate, monitor, and control production equipment while also helping improve manufacturing processes and schedules to meet customer requirements.

-This program certifies the apprentice with a full CPT or CPT+ and represents 160-170 hours of the 260 hours of Related Instruction under the IMT program, with the On the Job Learning taking up the remaining 2736 hours.

1IRRjRJSw

Minds-i Drone Gimbal Rig - Perfect for Testing Indoors!

Are you looking for a way to test your Minds-i UAV without risk of damage in a controlled environment? Look no further than the UAV Drone Gimbal Rig from Minds-i!  The MINDS-i Drone Gimbal's Rig 3-axis system gives users the ability to practice the complete range of flying capabilities while piloting a MINDS-i UAV, all in a stationary position. This allows you to introduce UAV flight controls and best practices to anyone, regardless of skill level or age in a safe and controlled indoor environment making it the perfect fit for the classroom.

Drone Gimbal Rig
